On August 14th, Weihua 180t metallurgical casting crane, 90t+90t feeding semi-gantry crane, 100t bridge crane, etc., a total of seven multi-series cranes set off. About to go to Kazakhstan to serve a project of a steel group in Kazakhstan.

Exported to Kazakhstan multi-series crane loading site

Centralized departure of export projects to Kazakhstan

This series of metallurgical cranes is designed in accordance with the FEM standard, guided by the modular design theory, and by means of modern computer technology. For the production environment with a large temperature difference on the customer's application site, it is completed with new materials and new processes. Intelligent and high-tech new metallurgical crane.

180t casting crane technical features:

1. The machine adopts a new type of rigid bridge structure with four beams, four rails and double trolleys, and the working level reaches A8;

2. Compared with similar products, the self-weight is reduced by 10%, the height is reduced by 25%, and the width is reduced by 25%; the product can be applied to the ambient temperature of -40°C to +60°C;

3. The new type of tow cable power supply device that is resistant to high temperature radiation can operate reliably under the condition of thousands of degrees of high temperature radiation.

Technical features of 90t+90t ton feeding semi-gantry crane:

1. This product is a special feeding semi-gantry crane for steel mills. The lifting capacity of the whole machine is 90t+90t, the lifting height is 24m, and the working level is A8;

2. The product has been newly designed for the problems of limited production space, high risk factor of skew-pulling and hoisting during feeding, and excessive wire rope skew-pulling angle, which is an innovative product for the company;

3. It adopts the structure of three beams and four rails, and two independent lifting mechanisms are designed on a single trolley, equipped with a special four-point gantry hook spreader, and the two lifting mechanisms can realize the function of hopper dumping and feeding through their independent actions;

4. Carry out the finite element optimization check calculation of the overall structure, simulate the actual operating conditions of the crane, and reduce the dead weight and the wheel pressure of the whole machine by 10% compared with similar products.

The steel group is one of the world's best steel manufacturers, employing 320,000 people in more than 60 countries, and the group's annual output accounts for about 10% of the world's total steel production. The 7 multi-series cranes of Weihua serve a project in Kazakhstan of the iron and steel group, which will help the iron and steel group to further expand the iron and steel industry in Kazakhstan and continue to expand the international market.
